Spiral Wound Gaskets


Sprial Wound

A complete range of sizes in stock

Sprial wound gaskets

Custom made Spiral Wound Gaskets

available for a wide range of applications:

Sprial wound gaskets are the industry standard for Refineries, power, chemical, wastewater, pulp and paper etc. They are generally used for applications over 150# pressure class. Made of a range of metals, Spiral wound gaskets work by having a compressive load squeeze the metal widings which because of there v shape have the ability to recover from compression. Spiral wound gaskets must contain an appropriate filler between the winding for the application. When looking for a high pressure and high temperature gasket Sprial wound gaskets are the industries standard.

     Manhole &  Hand hole  -  Large Diameter Gaskets   -  Tongue and groove
    Valve Bonnet    -  Guideless gasket applications - Custom Designs  -   Boiler type

Spiral Wound Gasket Brochure

Spiral Wound Gasket Information

For standard spiral wound descriptions  click here

Materials Available:

    Filler Materials: Non-Asbestos,  PTFE,  GRAFOIL®, Ceramic

    Windings Strips: 304, 316 Stainless are most common however others include: Hastalloy ®, Alloy 20, Monel ®, Nickel ®, Inconel ®, Incoloy ®, Duplex, Zirconium ®,Tantalum ®, Copper, Bronze, Carbon Steel

    Manufacurer Brands we have supplied Lammons, Garlock, FMI, Leader Gasket, AS&P

    Sprial Wound Gasket dimensions

    Spiral Wound Gasket sizes designed for ASME / ANSI B 16.5 & BS 1560 Flanges.
    150# through 2500# pressure designs.
